3000-7000LBS Four Wheel Lithium Forklift
1. Lithium battery is more environmentally friendly, maintenance-free, long life and high efficient.
2. The controller is installed on the balance weight, and the heat balance temperature is low
Description
1. Lithium battery is more environmentally friendly, maintenance-free, long life and high efficient.
2. The controller is installed on the balance weight, and the heat balance temperature is low
3. Strengthened steering axle with high supporting point increase the bearing capacity; increased cylinder
diameter reduces steering pressure and steering energy consumption.
4. The center of gravity is reduced through tail-free structure and thus truck stability is improved.
| Item | Four wheel Forklift (Lithium-ion) 80V (3000–3600 lbs. Capacity) | Four wheel Forklift (Lithium-ion) 80V (4000–7000 lbs. Capacity) | |||||
|---|---|---|---|---|---|---|---|
| Model Designation | CPD15 | CPD18 | CPD20 | CPD25 | CPD30 | CPD35 | |
| Load Capacity (lbs) | 3000 | 3600 | 4000 | 5000 | 6000 | 7000 | |
| Load Center (in) | 24 | ||||||
| Dimensions | |||||||
| Overhead Guard Height (in) | 83.9 | 85.4 | 85.8 | ||||
| Overall Length (without fork) (in) | 86.6 | 95.7 | 101.1 | 101.3 | |||
| Overall Width (in) | 44.1 | 46.5 | 49.6 | ||||
| Min. Outside Turning Radius (in) | 75.6 | 84.3 | 88 | ||||
| Wheels, Chassis | |||||||
| Tyre (front) | 6.50–10–10PR | 7.00–12–14PR | 28×9–15–14PR | ||||
| Tyre (rear) | 16×6–8–10PR | 18×7–8–14PR | 18×7–8 | ||||
| Tyre Type | Pneumatic tyre | Front Pneumatic / Rear Solid | |||||
| Weight | |||||||
| Total weight (with/without battery) (lbs) | 6294/5897 | 6548/6151 | 7904/7485 | 8653/8234 | 10031/9502 | 10714/10185 | |
| Performance | |||||||
| Travel Speed, loaded/unload (mph) | 9 / 9.3 | ||||||
| Lifting Speed, loaded/unload (fpm) | 42.9 / 59.0 | ||||||
| Max. Gradeability, loaded/unload (%) | 17 / 27 | 15 / 26 | 17 / 26 | 15 / 25 | 17 / 26 | 15 / 23 | |
| Battery Voltage / Rated Capacity (V/Ah) | 80/150 | 80/202 | 80/250 | ||||
| Drive Motor – 60 Min. Rating (HP) | 10.7 | 14.8 | 20.1 | ||||
| Pump Motor – 15 Min. Rating (HP) | 14.2 | 16.1 | 21.5 | ||||
| Drive Motor Control Method | MOSFET / AC | ||||||
| Controls | immotion | ||||||
| Lead Acid Optional | ○ optional – non-configurable | ||||||
