CQDH15R
Electronic power steering system, light and low noise.
Electromagnetic, regenerative braking system. Lifting, reach regenerative limit motor and battery life.
Description
Electronic power steering system, light and low noise.
Electromagnetic, regenerative braking system. Lifting, reach regenerative limit motor and battery life.
Standard moon walk. Handle at any angle, the vehicle goes straight.
Curve automatic deceleration devices, more safe.
Stepless speed control system, safe and quiet.
Emergency reversing device/ Emergency brake switch.
High position automatic reduction device.
| Model | CODH15R | |
|---|---|---|
| Type | Single Scissor With Platform (Magnetic-valve) | Double Scissor With Platform (Magnetic-valve) |
| Mast type | – | – |
| Loading capacity | 3000 lbs | |
| Load center | 20 in | |
| Operating type | Walkie | |
| Wheels type | PU | |
| Lift height | 98/118/138/157/177/197/217 in | 118/138/157/177/197/217 in |
| Max extend height | 133/153/172/192/212/235/251 in | 159/179/198/218/238/258 in |
| Mast lowered height | 74/83/93/103/86/92/98 in | 84/94/103/86/92/99 in |
| Overall length | 93/94 in | 100/101 in |
| Overall width | 41/51/37 in | 49/37 in |
| Min.Turning radius | 66.6/67.3 in | 68.6/69.4 in |
| Min.Asle width for pallets 1000×1200 | 111.6/112.9 in | 112.6/113.5 in |
| Travel speed,laden/unladed | 2.98/3.11 mph | |
| Lift speed,laden/unladed | 18.7/23.6 in/s | |
| Battery voltage/capacity | 24/320(460) V/Ah | |
| Controller | ||
| Battery weight | 570(720) lbs | |
| Service weight with battery | 4500/4600/4700/5000/5100/5200 lbs | 4660/4760 lbs |
| Reach distance | 19.7 in | 47.2 in |
